![Daikin EWAD650BJYNN/Q [29/346] Esie07 04 general outline](/img/pdf.png)
Daikin EWAD650BJYNN/Q [29/346] Esie07 04 general outline
![Daikin EWAD650BJYNN/Q [29/346] Esie07 04 general outline](/views2/1660213/page29/bg1d.png)
ESIE07-04 General Outline
Part 1 – System Outline 1–17
3
1
4
5
Note: (1) Cooling capacity and power input are based on 12/7 °C entering/leaving water temp. and 35°C air ambient
temp.Power input is for compressor only.
Note: (1) Cooling capacity and power input are based on 12/7 °C entering/leaving water temp. and 35°C air ambient
temp.Power input is for compressor only.
Weight and dimensions
Standard unit shipping weight kg 6563 8420 8420 8950 8950 9390 9540
Standard unit operating weight kg 6967 8830 8830 9360 9360 9800 9950
Unit length mm 8300 9200 9200 10100 10100 11000 11000
Unit width mm 2230 2230 2230 2230 2230 2230 2230
Unit height mm 2520 2520 2520 2520 2520 2520 2520
Model EWAD-BJYNN/A with OPRN
Unit size C10 C11 C12 C13 C14 C15 C16
Model EWAD-BJYNN/A with OPRN
Unit size C17 C18 C19 C20 C21
Cooling capacity (1) kW 1401 1512 1618 1762 1871
Power input (1) kW 408 501 541 572 594
COP 3.44 3.02 2.99 3.08 3.15
Screw compressors N° 3 4 4 4 4
Refrigerant circuits N° 3 4 4 4 4
Refrigerant charge R-134a kg 232 256 264 264 264
Oil charge kg 60 80 80 80 80
Min % of capacity reduction % 8.3 6.25 6.25 6.25 6.25
Condenser fans
No. of fans / nominal power fan kW 26/1 26/1 28/1 28/1 28/1
Fan speed rpm 680 680 680 680 680
Diameter mm 800 800 800 800 800
Total air flow m3/s 106.3 105.2 113.3 114.4 114.4
Evaporator
Evaporators / water volume N°/l 1/533 2/254+246 2/246+246 2/246+246 2/392+392
Max operating pressure bar 10.5 10.5 10.5 10.5 10.5
Water connection diameter mm 219.1 168.3 168.3 168.3 219.1
Condenser coil
Coil type Lanced fins - internally spiral wound tubes
Weight and dimensions
Standard unit shipping weight kg 10355 10960 11168 11368 12144
Standard unit operating weight kg 10931 11420 11678 11878 13036
Unit length mm 12800 12800 13670 13670 13670
Unit width mm 2230 2230 2230 2230 2230
Unit height mm 2520 2520 2520 2520 2520
