ESIE07-04 General Outline
Part 1 – System Outline 1–13
3
1
4
5
Note: (1) Cooling capacity and power input are based on 12/7 °C entering/leaving water temp. and 32°C air
ambient temp.
Power input is for compressor only.
Condenser coil
Coil type Lanced fins - internally spiral wound tubes
Weight and dimensions
Standard unit shipping weight kg 8190 8725 8725 9310 9310 9750
Standard unit operating weight kg 8610 9150 9150 9720 9720 10160
Unit length mm 8300 9200 9200 10100 10100 11000
Unit width mm 2230 2230 2230 2230 2230 2230
Unit height mm 2520 2520 2520 2520 2520 2520
Model EWAD-BJYNN/Q
Unit size 850 900 950 C10 C11 C12
