ESIE07-04 The Digital Controller
Part 2 – Functional Description 2–51
3
2
4
5
1
Fan settings for
units with option
OPLA and OPFS
This screen is visible only when VFD or SPEEDTR is selected.
If the unit is with option OPLA, these settings will be used to control the VFD fan.
If the unit is with option OPFS, these settings will be used to control all the fans of the circuit.
Condensation
setpoints for units
with option OPLA
and OPFS
These screens are visible only when VFD or SPEEDTR is selected.
These screens allow you to set the condensation regulations setpoints.
Integral time and derivative time are used by the PID regulation to calculate the actions needed to
reach the condensation setpoint.
Oil heating This screen allows you to enable/disable the oil heating control.
P Max. Speed : When 10.0 V output signal is given, fans will work at maximum speed
P Min. Speed : When 0.0 V output signal is given, fans will work at minimum speed
(switched off)
P Speed Up Time : Time that full speed signal is given to the fan to speed up at fan start-up
Inverter Config.
Max. Speed
Min. Speed
Speed Up Time
10.0 V
0.0 V
1 s
P Regul. Band : Condensation regulation band around the condensation setpoint
P Neutral Band : Condensation neutral band around the condensation setpoint
Cond Regulation
Regul. Band
Neutral Band
05.0 bar
00.0 bar
Cond. Regulation
Integral Time 600 s
Derivative Time 001 s
P Y : Oil heating function is enabled
P N : Oil heating function is disabled
Enable Oil Heating Control Y
