Daikin EWAD850BJYNN/A [244/346] Pump down configuration at compressor stop
![Daikin EWAD850BJYNN/A [244/346] Pump down configuration at compressor stop](/views2/1660213/page244/bgf4.png)
Functional Control ESIE07-04
2–104 Part 2 – Functional Description
3
1
2
4
5
3.21 Pump Down Configuration at Compressor Stop
Introduction When the unit is switched off (local, remote, thermostat) the pump down procedure will be executed.
Function
description
Pump down prodecure:
P request to shut down compressor
P close electronic expansion valve
P stop compressor or when one of the two conditions is met:
P max time of pump down = 30 seconds
P LP is below 1.2 bar
Pump Down Config
Enable
Max time
Min Press.
30 s
1.2 bar
