ESIE07-04 The Digital Controller

Part 2 – Functional Description 2–65

This screen allows you to set the number of compressor starts.

Remark : Same compressor timers screens (two previous screens) will be displayed for compressor

2 (C : 2)

Temperature

regulation settings

These screens allow you to set the parameters for the temperature regulation function.

Remark : These parameters are vital for a proper temperature regulation.

High chilled water

start

This screen allows you to set the high chilled leaving water start parameters.

P C : 1 : Compressor information of compressor circuit 1

P Reset Y : Reset compressor starts

P Adjust : Enter the compressor starts of this compressor. This has to be done whenever soft-

ware or controller is changed.

C : 1

Comp. Starts

Reset N

Adjust 000000

P Regul. Band : Regulation band

P Neutral Band : Neutral band around setpoint

P Max Pull Down Rate : Maximum pull down rate

Regul. Band 03.0 ˚C

Neutral Band 00.2 ˚C

Max Pull Down Rate 00.6 ˚C / min

Start-Up DT 02.6 ˚C

Shut Down DT 01.7 ˚C

P LWT : Leaving water temperature setpoint to activate the high chilled leaving

water

P Max Comp. Stage : Maximum compressor stage of the compressor if leaving water tempera-

ture is higher than LWT setpoint

High ChLWT start

LWT 25.0 ˚C

Max Comp. Stage 070 %
