1.14 Electrical Specifications: EWAD-BJYNN/A
Electrical
specifications
The table below contains the electrical specifications
Notes:
(1) Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%.
(2) Nominal current is based on: 12/7 °C entering/leaving evaporator water temperature and 35°C ambient temp.
(3) Maximum current is based on: 14/9 °C entering/leaving evaporator water temperature and 48°C ambient temp.
(4) Inrush current of biggest compressor + 75 % of nominal absorbed current of the other compressor + fans
current.
(5) Compressor FLA + fans current.
Model EWAD-BJYNN/A
Unit size 650 700 800 850 900
Standard voltage (1) 400 V - 3f - 50 Hz
Nominal unit current (2) A 412 434 464 494 485
Max compressor current (3) A 442 468 511 554 547
Fans current A 44 48 52 56 56
Max unit current (3) A 486 516 563 610 603
Max unit inrush current (4) A 821 842 846 872 872
Max unit current for wires sizing (5) A 538 590 633 676 676
Model EWAD-BJYNN/A
Unit size 950 C10 C11 C12 C13 C14
Standard voltage (1) 400 V - 3f - 50 Hz
Nominal unit current (2) A 480 491 631 651 686 713
Max compressor current (3) A 532 545 670 696 742 788
Fans current A 646472728080
Max unit current (3) A 596 609 742 768 822 868
Max unit inrush current (4) A 872 872 1012 1029 1037 1059
Max unit current for wires sizing (5) A 684 684 837 885 932 971
Model EWAD-BJYNN/A
Unit size C15 C16 C17 C18 C19 C20 C21
Standard voltage (1) 400 V - 3f - 50 Hz
Nominal unit current (2) A 748 722 723 928 988 970 998
Max compressor current (3) A 834 810 791 1022 1108 1095 1130
Fans current A 88 88 104 104 112 112 112
Max unit current (3) A 922 898 895 1126 1220 1207 1242
Max unit inrush current (4) A 1090 1090 1090 1291 1299 1299 1299
Max unit current for wires sizing (5) A 1018 1018 1034 1266 1352 1352 1352
