ESIE07-04 The Digital Controller
Part 2 – Functional Description 2–57
3
2
4
5
1
2.4.8 EXV Setting Menu
Operational
information
Using this menu you can set all EXV parameters. The parameters can only be modified by trained
individuals.
Warning screen These screens show you the warnings of the EXV driver.
Actual / Manual
positions
These screens show you the actual EXV position, and allows you to manually control the EXV.
Password : 0013
Switching between con-
trol board # 1 and # 2 :
EXV Setting
Insert Password 0000
EXV Settings 1
NO WARNINGS
EXV Settings 2
NO WARNINGS
P EXV Setting : Indicates the EXV settings from circuit 1 or 2 (3 or 4)
P Actual Position : Actual position of the expansion valve
P Manual Position : Setpoint in EXV manual mode for the expansion value
P En. EXV Manual
Auto : Automatic expansion regulation
Manual : Manual control of the expansion valve (only during trouble shooting)
EXV Settings 1
Actual Position 0000
Manual Position 0500
En. EXV Manual AUTO
EXV Settings 4
Actual Position 0000
Manual Position 0500
En. EXV Manual AUTO
