General Outline ESIE07-04
1–40 Part 1 – System Outline
3
1
1
4
5
1.24 Outlook Drawing: EWAD700BJYNN/A, EWAD700BJYNN/A+OPRN and
EWAD700BJYNN/A+OPLN
The illustration below shows the outlook, the dimensions and the installation and service space of the
unit (mm).
(Frame)
(Control box)
Air discharge
See
detail B
Fan arrangements and minimum
clearance requirements
See detail A
Isolators location
Detail "A" rubber isolator
Fixing bolt (not furnished)
Refer
Detail B
''Victaulic''coupling-furnished
Connecting pipe-furnished
Concrete footing
I.D. 13 N. 4 holes
786011-h
________
786010-m
Optional right hand
evaporator water
Version Condenser Type
Weight KG
Type (q/ty)
786010-m
(4 Pz.)
786010-h
(2 Pz.)
Shipping Operating A B C D E F
1080 1165 870 935 762 8125419 5624
Isolators load KG
Aluminum
Acrylic coated
Rubber isolators
EWAD70BJYNN/A
EWAD70BJYNN/A+OPRN
EWAD70BJYNN/A
EWAD70BJYNN/A+OPRN
EWAD70BJYNN/A+OPLN
1140 1225 930 995 762 8125659 5884
Aluminum
Acrylic coated
EWAD70BJYNN/A+OPLN
