General Outline ESIE07-04
1–24 Part 1 – System Outline
3
1
1
4
5
1.13 Electrical Specifications: EWAD-BJYNN/Q
Electrical
specifications
The table below contains the electrical specifications.
Notes:
(1) Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%.
(2) Nominal current is based on: 12/7 °C entering/leaving evaporator water temperature and 35°C ambient temp.
(3) Maximum current is based on: 14/9 °C entering/leaving evaporator water temperature and 40°C ambient temp.
(4) Inrush current of biggest compressor + 75 % of nominal absorbed current of the other compressor + fans
current.
(5) Compressor FLA + fans current.
Model EWAD-BJYNN/Q
Unit size 550 600 650 700 750 800
Standard voltage (1) 400 V - 3f - 50 Hz
Nominal unit current (2) A 414 439 468 512 556 605
Max compressor current (3) A 440 473 506 558 610 660
Fans current A 10 11 12 13 14 16
Max unit current (3) A 450 484 518 571 624 676
Max unit inrush current (4) A 796 797 819 820 854 958
Max unit current for wires sizing (5) A 456 505 554 594 634 685
Model EWAD-BJYNN/Q
Unit size 850 900 950 C10 C11 C12
Standard voltage (1) 400 V - 3f - 50 Hz
Nominal unit current (2) A 640 666 702 733 791 818
Max compressor current (3) A 693 726 759 811 863 895
Fans current A 161818202022
Max unit current (3) A 709 744 777 831 883 917
Max unit inrush current (4) A 958 980 1000 1002 1035 1070
Max unit current for wires sizing (5) A 733 783 831 872 911 952
