General Outline ESIE97–02
1–4 Part 1 – System Outline
1.2 Technical Specifications
EUWA(*)40-60JX In the following table you will find the technical specifications of chiller types EUWA(*)40-60JX:
Model EUWA(*)40JX EUWA(*)50JX EUWA60(*)JX
Nominal cooling
capacity
(1)
102 kW 131 kW 160 kW
Nominal cooling input
(1)
40 kW 53 kW 60 kW
Capacity steps
100-75-55-0 100-75-55-0 100-75-55-0
MAIN COMPONENTS
Compressor
type
speed
crankcase heater
model x n°
semi-hermetic single screw
2880 rpm
150 W
ZHA5LABL YE
semi-hermetic single screw
2880 rpm
150 W
ZHA7SABL YE
semi-hermetic single screw
2880 rpm
150 W
ZHA7LABL YE
Evaporator
type
min.water volume system
water flow rate
nom. water pressure drop
insulation material
2 pass, 1 circuit, shell & tube dry
expansion: ES-185
2400 l
Min: 146 Max: 584 l/min
12 kPa
PVC nitril foam
2 pass, 1 circuit, shell & tube dry
expansion: ES-220
3000 l
Min: 187.5 Max: 750 l/min
16 kPa
PVC nitril foam
2 pass, 1 circuit, shell & tube dry
expansion: ES-270
3680 l
Min: 230 Max: 918 l/min
8kPa
PVC nitril foam
Condenser
type
rows x stages x fin pitch
face area
nominal air flow
discharge
fan type
n° of fans
n° of motors x output
nominal speed
cross fin coil / Hi-X-tubes and
chromate coated waffle louvre
fins
2 x 50 x 2.0mm
8.4 m²
960 m³/min
vertical
direct drive propeller
4
4x500W
750 rpm
cross fin coil / Hi-X-tubes and
chromate coated waffle louvre
fins
2x50x2.0mm
8.4 m²
1092 m³/min
vertical
direct drive propeller
4
4x1200W
900 rpm
cross fin coil / Hi-X-tubes and
chromate coated waffle louvre
fins
3 x 50 x 2.0mm
8.4 m²
960 m³/min
vertical
direct drive propeller
4
4x1200W
900 rpm
Piping connections
evap. water in/outlet
evaporator water drain
relief device outlet
flexible joint Ø 114.3
1/2”FPT
1”NPT
flexible joint Ø 100
1/2”FPT
1”NPT
flexible joint Ø 141.3
1/2”FPT
1”NPT
Refrigerant circuit
refrigerant type
refrigerant charge
refrigerant control
oil type
oil charge volume
n° of circuits
R134a
30 kg
thermostatic expansion valve
NISSEKI RB68P
9l
1
R134a
34 kg
thermostatic expansion valve
NISSEKI RB68P
10.5 l
1
R134a
48 kg
thermostatic expansion valve
NISSEKI RB68P
10.5 l
1
Dimensions (h x w x d) 2135 x 3980 x 1110 mm 2135 x 3980 x 1110 mm 2135 x 3980 x 1110 mm
Weight
Machine weight
Operation weight
1355 kg
1403 kg
1487 kg
1542 kg
1650 kg
1743 kg
+0.5
+0
+0.5
+0
+0.5
+0
