ESIE97–02 Maintenance
Part 5 – Maintenance 5–5
1.3 Periodical Checks
Electrical checks
Refrigerant checks
Fan check
Water checks
Noise checks
Inspection checks and actions Remarks
Check that all electrical wiring are properly con-
nected and securely tightened. Check the electrical
components on damage or loss.
—
Check if the power supply corresponds with the iden-
tification label of the unit.
—
Check the operation of the circuit breaker and the
earth leak detector of the local supply panel.
—
Inspection checks and actions Remarks
Check the refrigerant circuit.
- If the unit leaks, contact your dealer.
- If the sight glass shows a wet condition or bubbles
combined with a full refrigerant charge, then it indi-
cates an refrigerant imbalance or unstable running
conditions. If a dry condition is not appeared within
12 operating hours, the filter drier must be changed.
—
Inspection checks and actions Remarks
Clean the cooling ribs of the fan motor if it is dirty. —
Inspection checks and actions Remarks
Check the water condition.
1. Drain the water from the air release plug.
2. If the water is dirty, replace all the water in the sys-
tem.
3. Check the water connection.
Dirty water causes a cooling capacity drop
as well as corrosion of the water heat
exchanger and pipe.
Inspection checks and actions Remarks
Check for any abnormal noise.
1. Locate the noise producing section and search
the cause.
2. If the cause of the noise cannot be located, con-
tact your dealer.
—
