General Outline ESIE97–02
1–12 Part 1 – System Outline
For a description of the components of the outlook drawings, refer to ‘Main components table’ on
page 12.
Main components
table
The following table introduces the different parts of the outlook drawings for EUWA(*)40-60JX and
EUWA(*)80-120JX:
*: Only for EUWAS 40-120 JX.
N° Components
1 Evaporator
2 Condenser
3 Compressor 1
4 Discharge stopvalve
5 Liquid stopvalve
6 Suction stopvalve*
7 Chilled water in
8 Chilled water out
9 Water drain evaporator
10 Air purge evaporator
11 Leaving water temperature sensor
12 Entering temperature sensor
13 Ambient temperature sensor
14 Drier + charge valve
15 Power supply intake
16 Emergency stop
17 Switchbox
18 Digital display controller
19 Field wiring intake
20 Main isolator switch (optional)
21 Compressor 2
