General Outline ESIE97–02
1–6 Part 1 – System Outline
EUWA(*)80-120JX In the following table you will find the technical specifications of chiller types EUWA(*)80-120JX:
Model EUWA(*)80JX EUWA(*)100JX EUWA(*)120JX
Nominal cooling
capacity
(1)
206 kW 276 kW 320 kW
Nominal cooling input
(1)
77 kW 107 kW 125 kW
Capacity steps
100-88-76-63-50-38-25 100-88-76-63-50-38-25 100-88-76-63-50-38-25
MAIN COMPONENTS
Compressor
type
speed
crankcase heater
model x n°
semi-hermetic single screw
2880 rpm
2x150W
2 x ZHA5LABL YE
semi-hermetic single screw
2880 rpm
2x150W
2 x ZHA7SABL YE
semi-hermetic single screw
2880 rpm
2x150W
2 x ZHA7LABL YE
Evaporator
type
min.water volume system
water flow rate
nom. water pressure drop
insulation material
2 pass, 1 circuit, shell & tube dry
expansion: ED-360
2400 l
Min: 235 Max: 1165 l/min
14 kPa
PVC nitril foam
2 pass, 1 circuit, shell & tube dry
expansion: ES-220
3000 l
Min: 335 Max: 1665l/min
12 kPa
PVC nitril foam
2 pass, 1 circuit, shell & tube dry
expansion: ES-270
3680 l
Min: 335 Max: 1665 l/min
15 kPa
PVC nitril foam
Condenser
type
rows x stages x fin pitch
face area
nominal air flow
discharge
fan type
n° of fans
n° of motors x output
nominal speed
cross fin coil / Hi-X-tubes and
chromate coated waffle louvre
fins
2 x 50 x 2.0mm
16.8 m²
1920 m³/min
vertical
direct drive propeller
8
8x500W
720 rpm
cross fin coil / Hi-X-tubes and
chromate coated waffle louvre
fins
2x50x2.0mm
16.8 m²
8 x 273 m³/min
vertical
direct drive propeller
8
8x1200W
900 rpm
cross fin coil / Hi-X-tubes and
chromate coated waffle louvre
fins
3 x 50 x 2.0mm
16.8 m²
1920 m³/min
vertical
direct drive propeller
8
8x1200W
900 rpm
Piping connections
evap. water in/outlet
evaporator water drain
relief device outlet
flexible joint Ø 141.3
1/2”FPT
1”NPT
flexible joint Ø 168.3
1/2”FPT
1”NPT
flexible joint Ø 168.3
1/2”FPT
1”NPT
Refrigerant circuit
refrigerant type
refrigerant charge
refrigerant control
oil type
oil charge volume
n° of circuits
R134a
2x35kg
thermostatic expansion valve
NISSEKI RB68P
2x9 l
1
R134a
2 x41 kg
thermostatic expansion valve
NISSEKI RB68P
2 x 10.5 l
1
R134a
2x44kg
thermostatic expansion valve
NISSEKI RB68P
2x10.5 l
1
Dimensions (h x w x d) 3980 x 2210 x 2156 mm 3980 x 2210 x 2156 mm 3980 x 2210 x 2156 mm
Weight
Machine weight
Operation weight
2450 kg
2530 kg
2680 kg
2814 kg
2900 kg
3025 kg
+0.5
+0
+0.5
+0
+0.5
+0
