12
Petrol chainsaw
GENERAL SAFETY PRECAUTIONS
Before using a new chain saw please read this manual
carefully.
WARNING! Under no circumstances may the
design of the machine be modifi ed without
the permission of the manufacturer. Always
use genuine accessories. Non-authorized modifi ca-
tions and/or accessories can result in serious personal
injury or the death of the operator or others.
WARNING! A chain saw is a dangerous tool if
used carelessly or incorrectly and can cause
serious, even fatal injuries. It is very impor-
tant that you read and understand the contents of this
operator’s manual.
WARNING! Running an engine in a confi ned
or badly ventilated area can result in death
due to asphyxiation or carbon monoxide poi-
soning.
PERSONAL PROTECTIVE EQUIPMENT
● Approved protective helmet
● Hearing protection
● Protective goggles or a visor
● Gloves with saw protection
● Trousers with saw protection
● Boots with saw protection, steel toe-cap and non-
slip sole
Generally clothes should be close-fi tting without re-
stricting your freedom of movement.
MACHINE'S SAFETY EQUIPMENT
The life span of the machine can be reduced and the
risk of accidents can increase if machine maintenance
is not carried out correctly and if service and/or repairs
are not carried out professionally. If you need further
information please contact your nearest service work-
shop.
WARNING! Never use a machine with defec-
tive safety components. Safety equipment
must be inspected and
maintained. See instructions under the heading Check-
ing, maintaining and servicing chain saw safety equip-
ment. If your machine does not pass all the checks,
take the saw to a servicing dealer for repair.
CHAIN BRAKE AND FRONT HAND GUARD
Your chain saw is equipped with a chain brake that is
designed to stop the chain if you get a kickback. The
chain brake reduces the risk of accidents, but only you
can prevent them.
Take care when using your saw and make sure the
kickback zone of the bar never touches any object.
● The chain brake can either be activated manually
(by your left hand) or automatically by the inertia re-
lease mechanism.
● The brake is applied when the front hand guard is
pushed forwards.
● This movement activates a spring-loaded mecha-
nism that tightens the brake band around the engine
drive system (clutch drum).
● The front hand guard is not designed solely to ac-
tivate the chain brake. Another important feature is
that it reduces the risk of your left hand hitting the
chain if you lose grip of the front handle.
● The chain brake must be engaged when the chain
saw is started to prevent the saw chain from rotat-
ing.
● Use the chain brake as a ”parking brake” when
starting and when moving over short distances, to
reduce the risk of moving chain accidentally hitting
your leg or anyone or anything close by.
● To release the chain brake pull the front hand guard
backwards, towards the front handle.
● Kickback can be very sudden and violent. Most
kickbacks are minor and do not always activate the
chain brake. If this happens you should hold the
chain saw fi rmly and not let go.
● The way the chain brake is activated, either manu-
ally or automatically by the inertia release mecha-
nism, depends on the force of the kickback and the
position of the chain saw in relation to the object that
the kickback zone of the bar strikes.
If you get a violent kickback while the kickback zone
of the bar is farthest away from you the chain brake is
designed to be activated by the inertia in the kickback
direction.
VIBRATION DAMPING SYSTEM
Your machine is equipped with a vibration damping
system that is designed to minimize vibration and make
operation easier.
The machine′s vibration damping system reduces the
transfer of vibration between the engine unit/cutting
equipment and the machine′s handle unit. The body of
the chain saw, including the cutting equipment, is insu-
lated from the handles by vibration damping units.
Cutting hardwoods (most broadleaf trees) creates
more vibration than cutting softwoods (most conifers).
Cutting with cutting equipment that is blunt or faulty
(wrong type or badly sharpened) will increase the vi-
bration level.
