(12~48V)(B-Type only)
65
40~60W Desktop Type
Features
• Universal AC input / Full range
• Medical safety approved(2xMOPP)
• Suitable for BF application with appropriate system consideration
(B-Type only)
• Extremely low leakage current
• No load power consumption <0.1W
• Energy efficiency Level VI (5~9V for Level V)
• Comply with EISA 2007/DoE, NRCan, AU/NZ MEPS, EU ErP and meet
CoC Version 5
GSM40A/60A GSM40B/60B
General Specification (Please refer to www.meanwell.com for detail spec.)
Order No. GSM40A GSM40B GSM60A GSM60B
AC input voltage range 80~264VAC; 113~370VDC
Leakage current
$7\SHȝ$%7\SHȝ$
AC inrush current (max.) Cold start, 60A at 230VAC
Overload
protection
Range 105%~160% rated output power
Type Hiccup mode, auto-recovery
Over voltage
protection
Range 105%~135% rated output voltage
Type Shut down o/p voltage, re-power on to recover
Setup, rise, hold up time 1000ms, 30ms, 50ms
Withstand voltage
A-Type: I/P-O/P: 4kVAC, I/P-FG: 2kVAC, O/P-FG: Short
B-Type: I/P-O/P: 4kVAC
Working temperature
-30~+70°C (refer to output derating curve)
Safety standards
A-Type: ANSI/AAMI ES60601-1, CAN/CSA-C22 / TUV EN60601-1 approved
B-Type: ANSI/AAMI ES60601-1, CAN/CSA-C22 /
ES60601-1-11, TUV EN60601-1 / EN60601-1-11 approved
EMC standards EN55011 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61204-3, EN60601-1-2 medical level, FCC Part 15 class B
Length of output cable
100cm of UL2464, 16AWG for GSM40 5~7.5V and GSM60 5~15V
100cm of UL1185, 16AWG for GSM40 9~12V
150cm of UL1185, 16AWG for GSM40 15~48V and GSM60 18~48V
Standard DC plug
(refer to page 62 for DC plug list)
P1J: 2.1øx5.5øx11mm/c+, tuning fork type
Dimension (LxWxH)(mm) 125x 50x 31.5
• High efficiency up to 91.5%
• A-Type: Class I(with earth Pin)
B-Type: Class II(without earth Pin)
• Protections: Short circuit / Overload / Over voltage / Over temp.(GSM60 A/B)
• Fully enclosed plastic case
• LED indicator for power on
• Optional lock type DC plug
• 3 years warranty
Medical Adaptor
Order No. Output Tol. R&N Effi.
GSM40A05-P1J 5V, 0.1~5A ±5% 80mV 81.0%
GSM40A07-P1J 7.5V, 0.1~5.34A ±5% 80mV 85.5%
GSM40A09-P1J 9V, 0.1~4.45A ±5% 100mV 86.0%
GSM40A12-P1J 12V, 0.1~3.34A ±3% 100mV 88.0%
GSM40A15-P1J 15V, 0.1~2.67A ±3% 100mV 88.5%
GSM40A18-P1J 18V, 0.1~2.22A ±3% 120mV 89.5%
GSM40A24-P1J 24V, 0.1~1.67A ±2.5% 150mV 90.0%
GSM40A48-P1J 48V, 0.1~0.84A ±2.5% 150mV 91.0%
Order No. Output Tol. R&N Effi.
GSM40B05-P1J 5V, 0.1~5A ±5% 80mV 81.0%
GSM40B07-P1J 7.5V, 0.1~5.34A ±5% 80mV 85.5%
GSM40B09-P1J 9V, 0.1~4.45A ±5% 100mV 86.0%
GSM40B12-P1J 12V, 0.1~3.34A ±3% 100mV 88.0%
GSM40B15-P1J 15V, 0.1~2.67A ±3% 100mV 88.5%
GSM40B18-P1J 18V, 0.1~2.22A ±3% 120mV 89.0%
GSM40B24-P1J 24V, 0.1~1.67A ±2.5% 150mV 90.0%
GSM40B48-P1J 48V, 0.1~0.84A ±2.5% 150mV 91.0%
Order No. Output Tol. R&N Effi.
GSM60A05-P1J 5V, 0.1~6A ±5% 80mV 81.5%
GSM60A07-P1J 7.5V, 0.1~6A ±5% 80mV 86.0%
GSM60A09-P1J 9V, 0.1~6A ±5% 100mV 87.5%
GSM60A12-P1J 12V, 0.1~5A ±3% 100mV 88.0%
GSM60A15-P1J 15V, 0.1~4A ±3% 100mV 88.5%
GSM60A18-P1J 18V, 0.1~3.33A ±3% 120mV 89.0%
GSM60A24-P1J 24V, 0.1~2.50A ±3% 150mV 90.5%
GSM60A48-P1J 48V, 0.1~1.25A ±2.5% 200mV 91.5%
Order No. Output Tol. R&N Effi.
GSM60B05-P1J 5V, 0.1~6A ±5% 80mV 81.5%
GSM60B07-P1J 7.5V, 0.1~6A ±5% 80mV 86.0%
GSM60B09-P1J 9V, 0.1~6A ±5% 100mV 87.5%
GSM60B12-P1J 12V, 0.1~5A ±3% 100mV 88.0%
GSM60B15-P1J 15V, 0.1~4A ±3% 100mV 88.5%
GSM60B18-P1J 18V, 0.1~3.33A ±3% 120mV 89.0%
GSM60B24-P1J 24V, 0.1~2.5A ±3% 150mV 90.0%
GSM60B48-P1J 48V, 0.1~1.25A ±2.5% 200mV 91.5%
Desktop (IEC 320-C14 / Class IŇ:
Desktop (IEC 320-C8 / Class IIŇ:
Desktop (IEC 320-C14 / Class IŇ:
Desktop (IEC 320-C8 / Class IIŇ:
