Charger

600~1600W Harsh Environment & Intelligent Battery Charger

• 3 stage charger for lead-acid batteries and Li-ion batteries

in harsh environment

• Universal AC input 90~305VAC

• Built-in active PFC function

• No load power consumption < 0.5W at remote OFF

• High efficiency up to 95.5%

• Fanless design, cooling by free air convection

• -40~+70°C wide operating range

• Aluminum case and filling with heat-conducted silicone

• Withstand 10G vibration test

• Operating altitude up to 5000 meters

• Vo and Io can be adjusted through internal potentiometer

• Protections: Short circuit / Over voltage / Over temperature

• 3 color LED loading indicator

• 6 years warranty

Model No. Output Effi.

HEP-600C-12

14.4V, 0~35.0A 93.5%

HEP-600C-24

28.8V, 0~21.0A 94.5%

HEP-600C-48

57.6V, 0~10.5A 95.5%

Model No. Output Effi.

RCB-1600-12

14.4V, 0~100A 90.5%

RCB-1600-24

28.8V, 0~55A 92.0%

RCB-1600-48

57.6V, 0~27.5A 93.0%

Model No. Output Effi.

RPB-1600-12

14.4V, 0~100A 91.0%

RPB-1600-24

28.8V, 0~55A 92.5%

RPB-1600-48

57.6V, 0~27.5A 93.5%

RCB-1600 Series

RPB-1600 Series

HEP-600 Series

• Intelligent charger with programmable 3 stage curve for lead-acid

batteries and Li-ion batteries

• Universal AC input / Full range

• Withstand 300VAC surge input for 5 seconds

• Built-in active PFC function

• Built-in I

C interface, PMBus protocol (optional CANBus)

• 1U low profile (41mm height)

• Rack mountable (RCB-1600), support hot swap (hot plug)

• Output voltage and current programmable

• Forced air cooling by built-in DC fan

• Built-in OR-ing FET

• Active current sharing up to 4800W (2+1) for RPB-1600,

8000W with one 19” rack shelf (RHP-1U

-A)for RCB-1600

• Protections: Battery under voltage / Battery no connection /

Short circuit / Over voltage / Over temperature

• 3 color LED loading indicator

• Optional conformal coating

• 5 years warranty

RPB-1600 RCB-1600

Features for HEP-600C Features for RPB-1600/RCB-1600

General Specification (Please refer to www.meanwell.com for detail spec.)

Order No. HEP-600C RPB-1600 RCB-1600

AC input voltage range 90~305VAC; 127~431VDC 90 ~ 264VAC; 127 ~ 370VDC

AC inrush current (max.) Cold start, 70A at 230VAC Cold start, 35A at 230VAC

DC adjustment range

Vo: 95%~125% rated output voltage

Vo: -1%~+22.5% by potentiometer, or to 75%~125% of

nominal output voltage by 1~5VDC

external control signal

Io: to 20%~100% of rated output current by 1-5VDC external

control signal

Over voltage protection 112%~142% shut down o/p voltage, re-power on to recover 130%~155% shut down o/p voltage, re-power on to recover

Working temperature -40~+70°C (refer to output derating curve) -30~+70°C (refer to output derating curve)

Withstand voltage I/P-O/P: 3.75kVAC, I/P-FG: 2kVAC, O/P-FG: 1.5kVAC I/P-O/P:3KVAC, I/P-FG:2KVAC, O/P-FG:1.5KVAC

Safety standards UL60950-1, TUV EN60950-1 approved

EMC standards EN55032 conduction class B, radiation class A; EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11

Connection 3+7P / 11mm pitch terminal block with cover bus bars Postronic PCIM34W13M400A1

Dimension(LxWxH)(mm) 280x 144x 48.5 300x 85x 41

HEP-600C
