A
Blank
INPUT OUTPUT
Standard
Optional
(Contact
MW for
details)
Best products also need best service.
We have authorized distributors all over the world. They have
sufficient stock for your prompt delivery. Also, they can offer
you technical support & RMA services. Please contact your
local distributors for more product information. You can also
contact us at
info@meanwell.com for information of your local
distributors.
85
Model No. Output Tol. R&N Effi.
HEP-100-12 A
12V, 0~8.34A ±1.0% 120mV 92%
HEP-100-15 A 15V, 0~6.67A ±1.0% 150mV 92%
HEP-100-24 A 24V, 0~4.00A ±1.0% 150mV 93%
HEP-100-36 A 36V, 0~2.65A ±1.0% 200mV 93%
HEP-100-48 A 48V, 0~2.00A ±1.0% 200mV 93%
HEP-100-54 A 54V, 0~1.77A ±1.0% 200mV 93%
= A or Blank, A: standard model(IP65), Blank: optional model(IP68)
Model No. Output Tol. R&N Effi.
HEP-185-12 A
12V, 0~13.0A ±2.5% 150mV 91.5%
HEP-185-15 A 15V, 0~11.5A ±2.0% 150mV 92.0%
HEP-185-24 A 24V, 0~7.80A ±1.0% 150mV 93.5%
HEP-185-36 A 36V, 0~5.20A ±1.0% 200mV 93.5%
HEP-185-48 A 48V, 0~3.90A ±1.0% 200mV 94.0%
HEP-185-54 A 54V, 0~3.45A ±1.0% 200mV 94.0%
= A or Blank, A: standard model(IP65), Blank: optional model(IP68)
Model No. Output Tol. R&N Effi.
HEP-150-12 A
12V, 0~12.5A ±2.5% 150mV 91.5%
HEP-150-15 A 15V, 0~10.0A ±2.0% 150mV 92.0%
HEP-150-24 A 24V, 0~6.30A ±1.0% 150mV 93.0%
HEP-150-36 A 36V, 0~4.20A ±1.0% 200mV 93.5%
HEP-150-48 A 48V, 0~3.20A ±1.0% 200mV 94.0%
HEP-150-54 A 54V, 0~2.80A ±1.0% 200mV 94.0%
= A or Blank, A: standard model(IP65), Blank: optional model(IP68)
Harsh Environment
100~185W Single Output
Features
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No. HEP-100 HEP-150 HEP-185
AC input voltage range 90~305VAC, 127~431VDC
AC inrush current (max.) Cold start, 60A at 230VAC Cold start, 65A at 230VAC
DC adjustment range
Vo: -10%~+10% by potentiometer (A-Type only)
Io: to 60%~100% of rated output current adjustment
by potentiometer(A-Type only)
Vo: -10%~+10% by potentiometer (A-Type only)
Io: to 50%~100% of rated output current
by potentiometer(A-Type only)
Overload protection 105%~125% constant current limiting, auto-recovery
Over voltage protection 108%~135% rated output voltage
Setup, rise, hold up time 500ms, 50ms, 16ms at full load and 230VAC
Withstand voltage I/P-O/P: 3.75kVAC, I/P-FG: 2kVAC, O/P-FG: 1.5kVAC
Working temperature -55~+70°C (refer to output derating curve)
Safety standards UL60950-1 approved ; Design refer to TUV EN60950-1
EMC standards EN55032 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
Connection
Input UL rated, SJTW 18AWGx3C(30cm)
Output SJTW 14AWGx2C(30cm)
Dimension (LxWxH)(mm) 220x 68x 38.8 228x 68x 38.8
• Universal AC input 90~305VAC
• Built-in active PFC function
• High efficiency up to 94%
• Fanless design, cooling by free air convection
• Ultra-wide operating range
• Meet 6kV surge immunity level
• Withstand 10G vibration test
• Operating altitude up to 5000 meters
• Protections:
Short circuit / Overload / Over voltage / Over temperature
• Multiple models for choice:
A-Type:
IP65 rated, Vo and Io can be adjusted through
internal potentiometer
• Blank-Type(option): IP68 rated, Vo and Io fixed
• Suitable for general industrial applications at high/low
temperature, high dust, high moisture, high vibration,
high salt or outdoor environment
• 6 years warranty
100W HEP-100
185W HEP-185
150W HEP-150
