![Daikin EUW(*)60КХ [3/40] Specifications](/views2/1685124/page3/bg3.png)
2
Specifications
NOMINAL CAPACITY, CAPACITY STEPS and NOMINAL INPUT
UNITS EUW*40KX EUW*60KX EUW*80KX EUW*100KX
NOMINAL CAPACITY
(1)
Cooling kW 120 190 249 290
Heating kW 149 237 313 362
CAPACITY STEPS % 100-74-48-12 (Start up) 100-74-48-36-12 (Start up)
NOMINAL INPUT Cooling kW 30 48.6 66.1 74
Heating kW 35.1 57.2 75.5 87.3
TECHNICAL SPECIFICATIONS
UNITS EUW*40KX EUW*60KX EUW*80KX EUW*100KX
DIMENSIONS Unit H mm 1,014 1,014 1,014 1,014
W mm 2,672 2,672 2,672 2,672
D mm 898 898 898 898
WEIGHT Machine weight kg 990 1,320 1,640 1,680
Operation weight kg 1,020 1,370 1,710 1,760
MATERIAL Polyester painted galvanised steel plate
COLOUR Ivory white / Munsell code 5Y7.5/1
SOUND LEVEL (2) Sound power (standard) dBA 90 96 96 98
Sound power (low noise
option)
dBA 87 90 90 92
EVAPORATOR Type Brased plate heat exchanger, one per circuit
Qty x model 1 x AC250Q-NP60 1 x AC250Q-NP96 1 x AC250Q-NP128 1 x AC250Q-NP162
Minimum water volume in the
system (3)
l 1,400 2,100 2,200 2,400
Water flow range (min./max.) l/min 172/660 272/1,038 357/1,284 416/1,284
Insulation material Polyethylene foam
CONDENSER Type Shell and tube
Qty x model m
2
1 x AS240 1 x AS350 1 x AS80T 1 x AS92T
Qty x model l/min 217/800 336/1,050 452/1,233 522/1,367
REFRIGERANT
CIRCUIT
Refrigerant type R-134a
Refrigerant charge kg 20 67 74 70
No. of circuits 1111
Refrigerant control Thermostatic expansion valve
COMPRESSOR Type Semi-hermetic single screw
Qty x model 1 x ZHA5LLFLYE 1 x ZHA7MLFLYE 1 x ZHA9SLFLYE 1 x ZHA9LLFLYE
Speed rpm 2,880 2,880 2,880 2,880
Refrigerant oil FVC68D
Refrigerant oil charge l
10 +
0.5
0
13 +
0.5
0
18 +
0.5
0
18 +
0.5
0
Crankcase heater W 150 150 150 150
PIPING
CONNECTIONS
Evap. water in/outlet 3″ victaulic 3″ victaulic 3″ victaulic 3″ victaulic
Condenser water in/outlet 2″1/2 victaulic 3″ victaulic 3″ victaulic 3″ victaulic
Condenser water drain M6 M6 M6 M6
Evaporator water drain Field installation
Relief device outlet 1 x 1″ 1x1″ 2x1″ 2x1″
SAFETY DEVICES Double TüV approved high pressure switches / Low pressure protection / Pressure relief valve
/ Compressor motor thermal protector / Compressor motor overcurrent relay / Discharge
temperature controller / Freeze up protection / Recycling and guard timer / Digital display
controller with electronic temperature control / Reverse phase protector
•
Water-cooled • R-134a • EUW*40-200KX
6
2
183
• Hydronic Systems • Chillers
