![Daikin EUW(*)80КХ [4/40] Specifications](/views2/1685124/page4/bg4.png)
NOMINAL CAPACITY, CAPACITY STEPS and NOMINAL INPUT
UNITS EUW*120KX EUW*140KX EUW*160KX EUW*180KX EUW*200KX
NOMINAL CAPACITY
(1)
Cooling kW 380 439 498 539 580
Heating kW 474 551 626 675 724
CAPACITY STEPS %
100-88-76-63-50-38-25-12
(Start up)
100-88-76-63-50-38-25-12
(Start up)
100-87-74-68-50-37-24-18-12 (Start up)
NOMINAL INPUT Cooling kW 97.2 115 132 140 148
Heating kW 114 133 151 163 175
TECHNICAL SPECIFICATIONS
UNITS EUW*120KX EUW*140KX EUW*160KX EUW*180KX EUW*200KX
DIMENSIONS Unit H mm 2,000 2,000 2,000 2,000 2,000
W mm 2,672 2,672 2,672 2,672 2,672
D mm 898 898 898 898 898
WEIGHT Machine weight kg 2,640 2,960 3,280 3,320 3,360
Operation weight kg 2,740 3,080 3,420 3,470 3,520
MATERIAL Polyester painted galvanised steel plate
COLOUR Ivory white / Munsell code 5Y7.5/1
SOUND LEVEL (2) Sound power (standard) dBA 99 99 99 100 101
Sound power (low noise
option)
dBA 93 93 93 94 95
EVAPORATOR Type Brased plate heat exchanger, one per circuit
Qty x model 2xAC250Q-NP96 AC250Q-NP128+
AC250Q-NP96
2x
AC250Q-NP128
AC250Q-NP162+
AC250Q-NP128
2x
AC250Q-NP162
Minimum water volume in the
system (3)
l 2,100 2,100 2,200 2,200 2,400
Water flow range (min./max.) l/min 544/2,076 692/2,322 714/2,568 773/2,568 832/2,568
Insulation material Polyethylene foam
CONDENSER Type Shell and tube
Qty x model m
2
2 x AS350 AS80T+AS350 2 x AS80T AS92T + AS80T 2 x AS92T
Water flow range l/min 672/2,100 788/2,283 904/2,466 974/2,600 1,044/2,734
REFRIGERANT
CIRCUIT
Refrigerant type R-134a
Refrigerant charge kg 2 x 67 67+74 2 x 74 74 + 70 2 x 70
No. of circuits 22222
Refrigerant control Thermostatic expansion valve
COMPRESSOR Type Semi-hermetic single screw
Qty x model 2 x ZHA7MLFLYE ZHA9SLYE+
ZHA7MLFLYE
2 x ZHA9SLFLYE ZHA9LLFLYE+
ZHA9SLFLYE
2 x ZHA9LLFLYE
Speed rpm 2,880 2,880 2,880 2,880 2,880
Refrigerant oil FVC68D
Refrigerant oil charge l
2x13+
0.5
0
13&18+
0.5
0
2x18+
0.5
0
2x18+
0.5
0
2x18+
0.5
0
Crankcase heater W 2 x 150 2 x 150 2 x 150 2 x 150 2 x 150
PIPING
CONNECTIONS
Evap. water in/outlet 3″ victaulic 3″ victaulic 3″ victaulic 3″ victaulic 3″ victaulic
Condenser water in/outlet 3″ victaulic 3″ victaulic 3″ victaulic 3″ victaulic 3″ victaulic
Condenser water drain M6 M6 M6 M6 M6
Evaporator water drain Field installation
Relief device outlet 2 x 1″ 3x1″ 4x1″ 4x1″ 4X1″
SAFETY DEVICES Double TüV approved high pressure switches / Low pressure protection / Pressure relief valve
/ Compressor motor thermal protector / Compressor motor overcurrent relay / Discharge
temperature controller / Freeze up protection / Recycling and guard timer / Digital display
controller with electronic temperature control / Reverse phase protector
•
Water-cooled • R-134a • EUW*40-200KX
2
Specifications
6
2
184
• Hydronic Systems • Chillers
