ELECTRICAL SPECIFICATIONS
UNITS EUW*120KX EUW*140KX EUW*160KX EUW*180KX EUW*200KX
POWER SUPPLY Y1 T1 Y1 T1 Y1 T1 Y1 T1 Y1 T1
NOMINAL
DISTRIBUTION
SYSTEM VOLTAGE
Phase
3∼ 3∼ 3∼ 3∼ 3∼ 3∼ 3∼ 3∼ 3∼ 3∼
Frequency Hz
50 50 50 50 50
Voltage V
400 230 400 230 400 230 400 230 400 230
Voltage tolerance %
±10 ±10 ± 10 ± 10 ± 10
UNIT Nominal running current A
198 343 211 365 224 388 242 419 260 450
Starting current A
250 433 177+250 307+433 177 307 254 440 254 440
Maximum running current A
266 460 343 524 420 588 452 714 484 838
Recommended fuses
according to IEC standard
269-2
aM
2x3x160gL/gG 2x3x300gL/gG
1x3x160gL/gG &
1x3x224gL/gG
1x3x300gL/gG &
1x3x400gL/gG
2x3x224gL/gG 2x3x400gL/gG
1x3x224gL/gG &
1x3x250gL/gG
1x3x500gL/gG &
1x3x400gL/gG
2x3x250gL/gG 2x3x500gL/gG
COMPRESSOR Phase
3∼ 3∼ 3∼ 3∼ 3∼ 3∼ 3∼ 3∼ 3∼ 3∼
Voltage V
400 230 400 230 400 230 400 230 400 230
Starting current A
250 433 177 307 177 304 254 440 254 440
Nominal running current A
99 171 112 194 112 194 130 225 130 225
Maximum running current A
133 230 210 294 210 294 242 419 242 419
Starting method
Star-delta
CONTROL CIRCUIT Phase
1∼ 1∼ 1∼ 1∼ 1∼
Voltage V
230 230 230 230 230
Recommended fuses aM
Factory installed
NOTES
1 Nominal cooling capacities are based on the following conditions:
Evaporator: 12°C/7°C; condenser: 30°C/35°C
Nominal heating capacities are based on the following conditions:
Evaporator: 12°C/7°C; condenser: 40°C/45°C
2 The sound pressure level is measured via a microphone at a certain distance from the unit. It is a relative value, depending on the distance
and acoustic environment. The sound power level is an absolute value indicating the ’’power’’ which a sound source generates.
3 Min. water volume system applicable at nominal conditions
•
Water-cooled • R-134a • EUW*40-200KX
2
Specifications
