ELECTRICAL SPECIFICATIONS
UNITS EUW*40KX EUW*60KX EUW*80KX EUW*100KX
POWER SUPPLY Y1 T1 Y1 T1 Y1 T1 Y1 T1
NOMINAL
DISTRIBUTION
SYSTEM VOLTAGE
Phase 3∼ 3∼ 3∼ 3∼ 3∼ 3∼ 3∼ 3∼
Frequency Hz 50 50 50 50
Voltage V 400 230 400 230 400 230 400 230
Voltage tolerance % ± 10% ± 10% ± 10% ± 10%
UNIT Starting current A 172 298 250 433 177 307 254 440
Nominal running current A 62 107 99 171 112 194 130 225
Maximum running current A 87 151 133 230 210 294 242 419
Recommended fuses
according to IEC standard
269-2
aM
3x100gL/gG 3x160gL/gG 3x160gL/Gg 3x250gL/gG 3x224gL/gG 3x355gL/gG 3x250gL/gG 3x425gL/gG
COMPRESSOR Phase 3∼ 3∼ 3∼ 3∼
Voltage V 400 230 400 230 400 230 400 230
Starting current A 172 298 250 433 177 307 254 440
Nominal running current A 62 107 99 171 112 194 130 225
Maximum running current A 87 151 133 230 210 294 242 419
Starting method Star-delta
CONTROL CIRCUIT Phase 1∼ 1∼ 1∼ 1∼
Voltage V 230 230 230 230
Recommended fuses aM Factory installed
•
Water-cooled • R-134a • EUW*40-200KX
2
Specifications
6
2
185
• Hydronic Systems • Chillers
