Daikin EUW(*)80КХ [40/40] Option
![Daikin EUW(*)80КХ [40/40] Option](/views2/1685124/page40/bg28.png)
Option
number
Option description
3 digit
code
Model-type (approval) Unit size
Availability
b d k m q s t 40 60 80 100 120 140 160 180 200
Standard unit VVVVVVVVVVVVVVVV
Not completely combinable options 1st digit
zh
Glycol application chilled water temperature down to -5°C
12 VVVVVVVVVVVVVVVV
Factory mounted
zl Glycol application chilled water temperature down to -10°C 24 VVVVVVVVVVVVVVVV
Factory mounted
Completely combinable options
2nd/3rd digit
OP01 Liquid line solenoid valve 2 VVVVVVVVVVVVVVVV
Factory mounted
OP03 Dual pressure relief valve on the condenser 1 V std VVVstd VVVVVVVVVV
Factory mounted
OP12 Suction stop valve 4 V std VVVstd VVVVVVVVVV
Factory mounted
OP52 Main isolator switch (only Y1-model) 8 VVVVVVVVVVVVVVVV
Factory mounted
OP57 A-meter, V-meter 16 VVVVVVVVVVVVVVVV
Factory mounted
OPCN Option Daikin Integrated Chiller Network 256 VVVVVVVVVVVVVVVV
Factory mounted
Available kit
EKCLWS Common leaving water kit VVVVVVVVVVVVVVVV
Kit
EKDCE Evaporator water collector double circuit VVVVVVVVVVVV
Kit
EKDCC Condenser water collector double circuit VVVVVVVVVVVV
Kit
EKAC60A BMS address card for single circuit VVVVVVVVVVV
Kit
EKAC120A BMS address card for double circuit VVVVVVVVVVVV
Kit
EKBMSBNA BMS gateway BACNET protocol VVVVVVVVVVVVVVVV
Kit
EKBMSMBA BMS gateway MODBUS protocol VVVVVVVVVVVVVVVV
Kit
NOTES
1 std = standard on unit
* Model type for ISPESL approval pressure vessels (B)
Model type for RLK approval (Dutch) (D)
Model type for TTK approval (Finland) (K)
Model type for SdM approval pressure vessels (M)
Model type for UDT approval (Q)
Model type for SA approval (S)
Model type for TU
¨
V approval pressure vessels (T) → BASIC MODEL
2 V Available
Not available
std Standard
Impossible option combinations: zh + zl
•
Water-cooled • R-134a • EUW*40-200KX
11
Accessories & options
6
11
226
• Hydronic Systems • Chillers
