Daikin EUW(*)80КХ [8/40] Leaving water condenser
![Daikin EUW(*)140КХ [8/40] Leaving water condenser](/views2/1685124/page8/bg8.png)
LEAVING WATER
CONDENSER
40 45 50
LWE
MODEL
CC HC PI CC HC PI CC HC PI
4 40 100 131 31.6 95 128 34.4 89 125 37.1
60 159 208 51 145 199 55.7 128 187 60.8
80 208 274 67.6 195 266 73 182 259 79.1
100 241 315 76.8 226 308 84.2 210 300 92.8
120 318 417 102 290 398 111 256 374 122
140 367 482 119 340 465 129 310 446 140
160 416 547 135 390 532 146 364 517 158
180 449 589 144 421 573 157 392 559 172
200 482 631 154 452 615 168 420 600 186
7 40 115 147 32.6 109 143 35.1 102 138 37.6
60 180 231 52.7 167 222 57.2 152 212 62.3
80 235 303 70.2 221 294 75.5 207 286 81.5
100 274 352 80 258 343 87.3 242 335 95.8
120 360 462 105 334 445 114 304 425 125
140 415 534 123 388 517 133 359 499 144
160 470 606 140 442 588 151 414 572 163
180 509 655 150 479 637 163 449 621 177
200 548 703 160 516 686 175 484 670 192
10 40 130 163 33.8 123 158 36 115 152 38.2
60 197 250 55.1 186 244 59.5 173 236 64.5
80 262 334 74.5 247 324 79.2 232 314 84.9
100 307 388 83.8 291 379 91 275 371 99
120 394 501 110 372 487 119 346 471 129
140 459 585 130 433 568 139 405 550 149
160 524 669 149 494 647 158 464 629 170
180 569 725 161 538 703 170 507 685 184
200 614 777 168 582 759 182 550 742 198
16 40 159 194 35.6 150 186 37.4 141 179 39.1
60 239 296 58.4 231 292 62.8 221 287 67.6
80 315 395 82.2 299 383 86.4 283 372 92.1
100 372 461 92.2 356 452 98.8 339 442 106
120 477 590 117 461 583 126 442 573 135
140 554 691 141 530 675 149 504 659 160
160 630 789 164 598 766 173 566 744 184
180 687 856 174 655 826 176 622 814 198
200 744 922 184 712 904 198 678 884 212
SYMBOLS
CC : Cooling capacity (kW)
HC : Heating capacity (kW)
PI : Power input (kW)
LWE : Leaving Water Evaporator (°C)
LWC : Leaving water condenser (°C)
NOTES
1 Cooling capacity (CAP)
CAP = Cooling capacity from table (kW)
Capacity is for chilled water range Dt = 2∼5°C
2 Power input (PC)
PI = Power input from table (kW)
Power input is total input kW: compressor + control circuit
+ pumps (kW)
3 Water flow rate (WFR)
WFR = (860 x CAP)/(60 x Dt) (l/min)
CAP = From above calculation
Dt = Dt = Chilled water temperature rise within 2-5°C
WFR should always be within the limits
4 No pumps are supplied with the unit, so the added power
input for the pumps is calculated as (WFR x Dp)/0.3 as fixed
by 6/C/003 (Dp = pressure drop from pressure drop curves).
This is for cooled and cooling water.
5 Heating capacity has been calculated as follows:
CC+PIx0.97
•
Water-cooled • R-134a • EUW*40-200KX
3
Capacity tables
3-1
Cooling / heating capacities for air conditioning applications
6
3
3-1
188
• Hydronic Systems • Chillers
