ASRock X58 Extreme6 [23/76] 2 3 2 3 2 3 2 3
![ASRock X58 Extreme6 [23/76] 2 3 2 3 2 3 2 3](/views2/1686721/page23/bg17.png)
2323
2323
23
Step4. Connect a VGA cable or a DVI cable to the monitor connector or the DVI
connector of the graphics card that is inserted to PCIE1 slot.
Step3. Align and insert ASRock SLI_Bridge_2S Card to the goldfingers on each
graphics card. Make sure ASRock SLI_Bridge_2S Card is firmly in place.
ASRock SLI_Bridge_2S Card
