BIOS SETUP UTILITY
Storage Configuration
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
SATAII Configuration
SATAII 1
SATAII 2
SATAII 3
SATAII 4
SATAII 5
SATAII 6
SATA3_1
SATA3_2
SATA3_3
SATA3_4
[Enhanced]
[Hard Disk]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Configure SATAII as
[IDE]
Disabled
Compatible
Enhanced
Options
SATA3_1 and SATA3_2 RAID Mode Setup
SATA3_1, 2 Operation Mode
Compatible Mode
SATA3_3, 4 Operation Mode
SATA3_5, 6 Operation Mode
[IDE]
[Auto]
[IDE]
[IDE]
3.4.43.4.4
3.4.43.4.4
3.4.4
Storage ConfigurationStorage Configuration
Storage ConfigurationStorage Configuration
Storage Configuration
SATAII Configuration
Please select [Compatible] when you install legacy OS. If native OS
(Windows
®
XP / Vista
TM
/ 7) is installed, please select [Enhanced]. Then in
the option “Configure SATAII as”, you are allowed to set the selection to
[IDE], [RAID] or [AHCI]. The default value is [IDE].
If you select [RAID] or [AHCI] mode, the options “Hot Plug” and “SATA Link
Power Management” will appear.
AHCI (Advanced Host Controller Interface) supports NCQ and other
new features that will improve SATA disk performance but IDE
mode does not have these advantages.
SATA3_1 and SATA3_2 RAID Mode Setup
SATA3_1, 2 Operation Mode
Use this item to select SATA3_1, 2 operation mode. Configuration mode:
[IDE], [AHCI] and [Disabled]. The default value is [IDE].
SATA3_3, 4 Operation Mode
Use this item to select SATA3_3, 4 operation mode. Configuration mode:
[IDE], [AHCI] and [Disabled]. The default value is [IDE].
SATA3_5, 6 Operation Mode
Use this item to select SATA3_5, 6 operation mode. Configuration mode:
[IDE], [AHCI] and [Disabled]. The default value is [IDE].
Compatible Mode
Use this item to select SATA3 compatible mode. Configuration options:
[Auto] and [Enabled]. The default value is [Auto].
