ASRock X58 Extreme6 [64/76] Chipset settings
![ASRock X58 Extreme6 [64/76] Chipset settings](/views2/1686721/page64/bg40.png)
6464
6464
64
-
C State package limit setting
Selected option will program into C State package limit register. This item
appears only when you set the item Intel (R) C-STATE tech. to [Enabled].
Configuration options: [Auto], [C3] and [C6]. The default value is [Auto].
3.4.23.4.2
3.4.23.4.2
3.4.2
Chipset ConfigurationChipset Configuration
Chipset ConfigurationChipset Configuration
Chipset Configuration
BIOS SETUP UTILITY
Chipset Settings
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
Advanced
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Primary Graphics Adapter
[PCI]
Onboard HD Audio
Front Panel
Onboard Lan
Onboard 1394
CIR10 Field 1
PCIE Max Payload Size
Intel VT-d
Good Night LED
Port80 LED after POST
APMC Control (L0s/L1)
[Auto]
[Auto]
[Enabled]
[Enabled]
[Enabled]
[128B]
[Disabled]
[Disabled]
[Enabled]
[Disabled]
Primary Graphics Adapter
This allows you to select [PCI] or [PCI Express] as the boot graphic adapter
priority. The default value is [PCI].
Onboard HD Audio
Select [Auto], [Enabled] or [Disabled] for the onboard HD Audio feature. If you
select [Auto], the onboard HD Audio will be disabled when PCI Sound Card is
plugged.
Front Panel
Select [Auto] or [Disabled] for the onboard HD Audio Front Panel.
Onboard Lan
This allows you to enable or disable the “Onboard Lan” feature.
Onboard 1394
This allows you to enable or disable the “Onboard 1394” feature.
CIR10 Field 1
Use this to enable or disable CIR10 Field 1. The default value of this feature
is [Enabled].
PCIE Max Payload Size
This determines the maximum TLP (Transaction Layer Packet) payload size
that can be supported by PCI Express controller. Configuration options:
[128B] and [256B]. The default value is [128B].
Intel VT-d
Use this to enable or disable Intel
®
VT-d technology (Intel
®
Virtualization
Technology for Directed I/O). The default value of this feature is [Disabled].
