5353
5353
53
STEP 1: Set Up BIOS.
A. Enter BIOS SETUP UTILITY Advanced screen Storage Configuration.
B. Set “SATAII Configuration” to [Enhanced], and then in the option “Configure
SATAII as”, please set the option to [AHCI].
STEP 2: Make a SATA / SATAII driver diskette.
Please make a SATA / SATAII driver diskette by following section 2.20.1 step 2 on
page 49.
STEP 3: Install Windows
®
XP / XP 64-bit OS on your system.
After making a SATA / SATAII driver diskette, you can start to install Windows
®
XP /
XP 64-bit on your system. At the beginning of Windows
®
setup, press F6 to install a
third-party AHCI driver. When prompted, insert the SATA / SATAII driver diskette
containing the Intel
®
AHCI driver. After reading the floppy disk, the driver will be
presented. Select the driver to install according to the mode you choose and the OS
you install. You may select: "Intel(R) ICH10R SATA AHCI Controller (Desktop - Win-
dows XP)" for Windows
®
XP or "Intel(R) ICH10R SATA AHCI Controller (Desktop -
Windows XP64)" for Windows
®
XP 64-bit.
2.212.21
2.212.21
2.21
Installing WindowsInstalling Windows
Installing WindowsInstalling Windows
Installing Windows
®
7 / 7 64-bit / Vista 7 / 7 64-bit / Vista
7 / 7 64-bit / Vista 7 / 7 64-bit / Vista
7 / 7 64-bit / Vista
TM TM
TM TM
TM
/ Vista/ Vista
/ Vista/ Vista
/ Vista
TMTM
TMTM
TM
64-bit / XP / XP 64-bit Without RAID Functions64-bit / XP / XP 64-bit Without RAID Functions
64-bit / XP / XP 64-bit Without RAID Functions64-bit / XP / XP 64-bit Without RAID Functions
64-bit / XP / XP 64-bit Without RAID Functions
If you want to install Windows
®
7 / 7 64-bit / Vista
TM
/ Vista
TM
64-bit / XP / XP 64-bit
OS on your SATA / SATAII HDDs without RAID functions, please follow below
procedures according to the OS you install.
2.21.1 Installing Windows2.21.1 Installing Windows
2.21.1 Installing Windows2.21.1 Installing Windows
2.21.1 Installing Windows
®
XP / XP 64-bit Without RAID XP / XP 64-bit Without RAID
XP / XP 64-bit Without RAID XP / XP 64-bit Without RAID
XP / XP 64-bit Without RAID
Functions Functions
Functions Functions
Functions
If you want to install Windows
®
XP / XP 64-bit OS on your SATA / SATAII HDDs
without RAID functions, please follow below steps.
Using SATA / SATAII HDDs with NCQ function
STEP 1: Set up BIOS.
A. Enter BIOS SETUP UTILITY Advanced screen Storage Configuration.
B. Set “SATAII Configuration” to [Enhanced], and then in the option “Configure
SATAII as”, please set the option to [IDE].
STEP 2: Install Windows
®
XP / XP 64-bit OS on your system.
Using SATA / SATAII HDDs without NCQ function
