SATA Power Connector
(4-pin SATA_PWR1)
(see p.10, No. 9)
2.4 Power Connectors
ATX 12V Power Connector
(4-pin ATX12V1)
(see p.10, No. 1)
Please connect a power
supply to this connector.
Please connect a SATA
power cable.
GND
+5V
+12V
GND
1
