1 x Printer port
1 x LPC Debug header
1 x CPU Fan connector (1 x 4-pin)
1 x Chassis Fan connector (1 x 3-pin)
4 pin 12V power connector
SATA power connector
2 x USB 2.0 headers (supports 3 USB 2.0 ports)
BIOS
16Mb AMI UEFI Legal BIOS with GUI support
Supports “Plug and Play”
ACPI 1.1 Compliance Wake Up Events
Supports jumperfree
SMBIOS 2.3.1 Support
Support CD Drivers
Hardware
Monitor
CPU/Chassis Temperature Sensing
CPU/Chassis Fan Tachometer
CPU Quiet Fan
Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
OS Microsoft
®
Windows
®
7 compliant
Certications
FCC, CE, WHQL
CAUTION!
1. N2600 only supports one SO-DIMM and 4GB of system memo-
ry.
2. Due to the operating system’s limitation, the actual memory size
of the reservation for system usage under Windows
®
32-bit op-
erating systems may be less than 4GB.
