ASRock IMB-146 Series [6/46] Specifications
![ASRock IMB-146 Series [6/46] Specifications](/views2/1693622/page6/bg6.png)
6
1.2 Specications
Platform
Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
ASRock DuraCaps (100% Japan-made high-quality Conduc-
tive Polymer Capacitors)
CPU
Intel
®
Dual-Core Atom
TM
CedarView Processor D2550/
N2600/N2800
Supports Hyper-Threading Technology
Chipset Intel
®
NM10 Express Chipset
Memory
Single Channel DDR3 memory technology
2 x 204-pin DDR3 SO-DIMM slots (see CAUTION 1)
Supports DDR3 1066/800 MHz SDRAM
Max. capacity of system memory: 8GB (see CAUTION 2)
Expansion
Slots
1 x mini-PCI Express slot
Graphics
Intel
®
PowerVR SGX545
Supports DirectX 9, Pixel Shader v3.0 and OGL 3.0
Max. shared memory 256MB
Four VGA Output options: D-Sub, 2 x LVDS and DVI
Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
Supports 2-CH/24bits LVDS with max. resolution up to
1920x1200 @ 60Hz
Supports DVI with max. resolution up to 1920x1200 @ 60Hz
Audio 2 CH Audio (Realtek ALC662 Audio Codec)
LAN
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
Realtek RTL8111E-VL
Supports Wake On LAN
Supports PXE
Rear Panel
I/O
1 x DC Jack
1 x PS/2 Keyboard/Mouse port
1 x D-Sub port
1 x Serial Port (RS-232)
4 x USB 2.0 Ports
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
Internal I/O
2 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and
Hot Plug
1 x COM port header
2 x LVDS connectors
1 x DVI connector
