Operation Manual EDBE81-327
22 Photocatalytic Air Purifiers
4.7 Trouble Shooting
Trouble Shooting
■
■■
■
Investigate the problem once again before requesting repairs.
Case Check Measure
Does not operate.
Is the power plug unplugged? Securely insert it.
Is the front panel correctly set? Securely set it.
Are the battery of the remote controller dead?
Replace with new battery. (Page 5)
The four airflow rate displays, LL (Quiet),
L (Low), M (Standard) and H (High) are
flashing at the same time.
Is there any foreign matter in the air outlet? Remove the foreign matter.
For other cases, contact a Daikin dealer.
Air does not come out.
Cleaning effect is not obtained.
Is the unit installed at a location where the
flow does not pass or are there obstructions
close to the unit?
Remove the obstruction.
Is there too much dust in the pre-filter or filter
roll?
Clean or replace. (Pages 8, 9)
Is too much odors or smoke being generated? For this case, contact a Daikin dealer.
Television screen is distorted.
Is a television or radio installed within 2m of
this unit or is an indoor antenna being used
close to this unit?
Separate the television, radio and indoor
antenna from this unit by 2m or more.
Is the power cord or antenna of the television
or radio close to this unit?
Separate the power cord and antenna of the
television or radio as much as possible away
from this unit.
During operation a crackling sound or a
buzzing sound are heard.
Is the plasma ionizer securely set? Securely set it.
Is dust adhering to the ionizing line of the
plasma ionizer (resin part)?
Clean the plasma ionizer. (Page 9)
Has water entered into the spurt hole moist-
ening the negative ionization assembly?
If the negative ionization assembly is dry, the
sound will go away.
Odor is coming from the air outlet.
Is a large amount of odor being generated
temporarily? (Many people smoking or grilling
meat.)
If operated, the odor will gradually go away.
If the pre-filter or plasma ionizer dirty? Clean it. (Pages 8, 9, 10)
Clean monitor (Dust) is red and does not
change.
Caused by dust clogging the inside of the dust
sensor.
Remove the dust from the dust sensor air
intake using nozzles for small spaces of an
electric vacuum cleaner.
If the dust is removed and the unit is manually
operated for about half a day, it will be
restored to a normal state. (Page 11)
Clean monitor (Dust) is green and does
not change.
