EDBE81-327 Troubleshooting
Photocatalytic Air Purifiers 27
1 Models Covered 5 Troubleshooting
*Be sure to insert/pull out the connector after
turning off the power. It may cause malfunction.
MC704VM
Diagnosis Remedy
Replace display
PCB.
Replace dust
sensor unit
It is not malfunc-
tion. The sensor is
detecting moisture
in the air.
• Change the
installation
location.
• Reset the power.
Replace display PCB
(Sensor is defective).
It is not malfunc-
tion.
• The sensor may
be operating as
room is over-
sized or open.
2 Method of Mal-
function Detection
3 Malfunction Deci-
sion conditions
4 Supposed Causes
• Display PCB is defective.
• Dust sensor unit is defective.
3. Sensor LED Remains Lit
