Troubleshooting EDBE81-327
24 Photocatalytic Air Purifiers
6. Troubleshooting
6.1 Basic Inspection
Troubleshooting with Airflow Rate Indicator
(1) Is the connector for the PCB plugged
in? Or is there any poor connection?
(2) Is the wire harness broken?
The airflow rate indicators flicker only when the DC fan is locked.
The airflow rate indicators flicker simultaneously.
