38 Photocatalytic Air Purifiers
Removal Procedure EDBE81-327
7.4 Removal of PCBs
Procedure Points
* The back cover has
been removed.
1. Removing the
inverter PCB
(1) Detach the connector
(CN1) and remove
the inverter PCB.
2. Removing the power
PCB
(1) Detach the
connectors (S2, S6,
S8, S9 and S10) on
the power PCB
(A1P).
WARNING
Make sure the unit is disconnected from
any power source before disassembly.
