Photocatalytic Air Purifiers 37
EDBE81-327 Removal Procedure
Procedure Points
(3) Remove the
photocatalyst filter.
* Handle with great care,
the photocatalyst filter is
made of paper.
4. Removing the
special lamp
(1) Detach the special
inverter lamp.
