36 Photocatalytic Air Purifiers
Removal Procedure EDBE81-327
Procedure Points
(2) Remove the
connector (CN2) from
the inverter PCB
(A3P).
3. Removing the
photocatalyst filter
(1) Remove the two
screws.
(2) Detach the
photocatalyst filter
holder.
Inverter PCB for
the special lamp
