14 15
English
Chapter 2 Installation
is is an ATX form factor (12'' x 10'', 30.5 cm x 25.4 cm) motherboard. Before you install
the motherboard, study the conguration of your chassis to ensure that the motherboard
ts into it.
Make sure to unplug the power cord before installing or removing the motherboard. Failure
to do so may cause physical injuries to you and damages to motherboard components.
2.1 Screw Holes
Place screws into the holes indicated by circles to secure the motherboard to the chassis.
ere are 8 mounting holes on this motherboard as indicated below.
Place screws into the holes indicated by circles to secure the motherboard to the chassis.
Rear I/O
Intel
C612
Remove the standoff
from the chassis
1. Attention! Before installing this motherboard, be sure to unscrew and remove the stand-
o at the marked location, under the motherboard, from the chassis, in order to avoid
electrical short circuit and damage to your motherboard.
2. Please be cautious to avoid motherboards from contact with the screws and avoid dam-
aging the components when installing the motherboard to the chassis.
3. Please make sure no screws or standos are le in the chassis. Otherwise, the mother-
board may be seriously damaged.
