1.2 Specications
EP2C612D8C
MB Physical Status
Form Factor ATX
Dimension 12'' x 10'' (30.5 cm x 25.4 cm)
Processor System
CPU Intel® Xeon® processor E5-2600 v3/v4* series
*BIOS version 2.0 or above is required.
Socket Dual Socket LGA 2011 R3
Chipset Intel® C612
System Memory
Capacity 8 x 288-pin DDR4 DIMM slots
Type - Quad Channel DDR4 memory technology
- Supports DDR4 2400*/2133/1866/1600 RDIMM and
LRDIMM
*Only E5-2600 V4 CPUs support DDR4 2400.
Voltage 1.2V
DIMM Sizes RDIMM: 32GB, 16GB, 8GB, 4GB
LRDIMM: 64GB, 32GB
Expansion Slot
PCIe 3.0 x 16 1 slot
PCIe 3.0 x 8 2 slots
Mezzanine Slot 1 slot (for Storage Mezzanine card)
Storage
SATA
Controller
C612: 10 x SATA3 6Gb/s, support Intel® RSTe 4.0 RAID 0, 1, 5,
10
Ethernet
Interface 1000 /100 /10 Mbps by Intel i210
LAN 2 x RJ45 GLAN by Intel® i210
1 x RJ45 Dedicated IPMI LAN port
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
Management
BMC Controller ASPEED AST2400
IPMI Dedicated
GLAN
- 1 x Realtek RTL8211E for dedicated management GLAN
Features - Watch Dog
- NMI
