ASRock EP2C612D8C [28/89] Expansion slots pci express slots
![ASRock EP2C612D8C [28/89] Expansion slots pci express slots](/views2/1694665/page28/bg1c.png)
22 23
English
2.6 Expansion Slots (PCI Express Slots)
ere are 3 PCI Express slots on this motherboard.
PCIE slot:
PCIE5 (PCIE 3.0 x16 slot, blue, from CPU 1) is used for PCI Express x16 lane width cards.
PCIE6 (PCIE 3.0 x8 slot, blue, from CPU 1) is used for PCI Express x8 lane width cards.
PCIE3 (PCIE 3.0 x8 slot, white, from CPU 2) is used for PCI Express x8 lane width cards.
Slot Generation Mechanical Electrical Source
PCIE 6 3.0 x8 x8 CPU 1
PCIE 5 3.0 x16 x16 CPU 1
PCIE 3 3.0 x8 x8 CPU 2
PCI Express Slot Conguration
PCIE 5 PCIE 6
Single PCIE Card x16 x0
Two PCIE Cards x8 x8
e PCIE3 slot shares lanes with the Mezzanine Slot (MEZZ1). e PCIE3 slot will be
disabled when the MEZZ1 slot is populated with a mezzanine card.
PCIE 3 MEZZ1
No Mini SAS HD Connector x8
Mini SAS HD Connector Connected x0 Populated
