EP2C612D8C
2 3
English
Graphics
Controller ASPEED AST2400
VRAM DDR3 16MB
Rear Panel I/O
VGA Port 1 x D-Sub
Serial Port 1 (COM1)
USB 3.0 Port 2
USB 2.0 Port 2
LAN Port RJ45: 2 + 1 (IPMI)
LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID Button/
LED
1
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, front
LAN LED, and system fault LED)
TPM Header 1
IPMB Header 1
Fan Header 2 x CPU Fan (4-pin), 5 x system Fan (4-pin) (4 front, 1 rear)
ATX Power 1 (24-pin) + 2 (8-pin)
USB 3.0 Header 1 ( support 2 USB 3.0)
USB 2.0 Header 1 ( support 2 USB 2.0)
Type A USB 3.0
Port
1
Speaker Header 1 (4-pin)
ermal Sensor
Header
1
ME Recovery
Jumper
1
PSU SMBus
Header
1
BMC SMBus
Header
3
SGPIO Header 2
System BIOS
BIOS Type 64Mb AMI UEFI Legacy BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8.0 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU Temperature Sensing
- System Temperature Sensing
