EP2C612D8C
24 25
English
Chassis ID1 Jumper
(3-pin CHASSIS _ID1)
(see p.7, No. 37)
Chassis ID2 Jumper
(3-pin CHASSIS_ID2)
(see p.7, No. 35)
Chassis ID3 Jumper
(3-pin CHASSIS_ID3)
(see p.7, No. 33)
Board Level SKU (Default) For 3U8G system, passive
GPGPU
Chassis ID1 Jumper
(3-pin CHASSIS _ID1)
(see p.7, No. 37)
Chassis ID2 Jumper
(3-pin CHASSIS_ID2)
(see p.7, No. 35)
Chassis ID3 Jumper
(3-pin CHASSIS_ID3)
(see p.7, No. 33)
For 3U8G system, active
GPGPU
Reserved for system level
use
Chassis ID1 Jumper
(3-pin CHASSIS _ID1)
(see p.7, No. 37)
Chassis ID2 Jumper
(3-pin CHASSIS_ID2)
(see p.7, No. 35)
Chassis ID3 Jumper
(3-pin CHASSIS_ID3)
(see p.7, No. 33)
Reserved for system level
use
Reserved for system level
use
