User’s Manual of VC-820M / VC-2400MR Series

1.4 Product Features

¾ VDSL Interface

VC-2400MR / VC-2400MR48

 24 Full-Duplex VDSL links via RJ-21(Telco-50) connector

 24 corresponding POTS lines via RJ-21(Telco-50) connector

 Built-in POTS splitter for each VDSL port

 Auto-speed function for VDSL2 link (by distance and cable quality)

VC-820M

 8 x RJ-11 connectors for VDSL2 connection

 8 x RJ-11 connectors for telephone/POTS connection

 Built-in POTS splitter for each VDSL port

 Auto-speed function for VDSL2 link (by distance and cable quality)

¾ Ethernet Interface

 2 10/100/1000Mbps TP and SFP shared combo interfaces

 Auto-MDI/MDI-X detection on Gigabit RJ-45 port

¾ VDSL2 Features

 Cost-effective VDSL2 link and central management solution

 ITU-T G.993.2 VDSL2 standard

 DMT (Discrete Multi-Tone) line coding VDSL

 Selectable bandwidth control and target SNR margin

 Built-in surge protection to against surge damage from high energy spike

 Voice and data communication can be shared on the existing telephone wire simultaneously

¾ Layer 2 Features

 Prevents packet loss Flow Control:

• IEEE 802.3x PAUSE frame Flow Control for Full-Duplex mode

• Back-Pressure Flow Control in Half-Duplex mode

 High performance Store and Forward architecture, broadcast storm control, runt/CRC filtering eliminates

erroneous packets to optimize the network bandwidth

 8K MAC Address Table, automatic source address learning and ageing

 Support VLAN:

• IEEE 802.1Q Tag-Based VLAN

• Port-Based VLAN

• Q-in-Q tunneling (Double Tag VLAN)

• GVRP for dynamic VLAN Management

• Private VLAN Edge (PVE / Protected Port )

 Supports Link Aggregation

• Up to 13 Trunk groups

• Up to 8 ports per trunk group with 1.6Gbps bandwidth (Full Duplex mode)

• IEEE 802.3ad LACP (Link Aggregation Control Protocol)

• Cisco ether-Channel (Static Trunk)

 Support Spanning Tree Protocol:
