User’s Manual of VC-820M / VC-2400MR Series

4.14.3 802.1x Port Configuration

In this page, you can select the specific port and configure the authorization state. The state provides No Authorization,

Force Authorized, Force unauthorized, and Authorize.

Figure 4-14-5: 802.1x Per Port Setting interface

The page includes the following fields:

Object Description

Fu (Force Unauthorized)

The specified port is required to be held in the unauthorized state.

Fa (Force Authorized)

The specified port is required to be held in the authorized state.

Au (Authorize)

The specified port is set to the Authorized or Unauthorized state in accordance

with the outcome of an authentication exchange between the Supplicant and the

authentication server.

The specified port works without complying with 802.1x protocol.

130
