User’s Manual of VC-820M / VC-2400MR Series

• STP, IEEE 802.1D (Classic Spanning Tree Protocol)

• MSTP, IEEE 802.1s (Multiple Spanning Tree Protocol, spanning tree by VLAN)

¾ Quality of Service

 4 priority queues on all switch ports

 Traffic classification:

• IEEE 802.1p Class of Service

• IP TOS / DSCP code priority

• Port Base priority

 Strict priority and weighted round robin (WRR) CoS policies

 Ingress/Egress Bandwidth control on each port

¾ Multicast

 IGMP Snooping v1 and v2

 IGMP Snooping v2 fast leave

 IGMP Query mode for Multicast Media application

¾ Security

 IEEE 802.1x Port-Based network access control protocol

 RADIUS users access authentication

 L3 / L4 Access Control List (ACL)

 Source IP-MAC / Port-Binding

 Port Security for Source MAC address entries filtering

¾ Management

 Switch Management Interface

- Telnet Command Line Interface

- Web switch management

- SNMP v1, v2c, v3 switch management

- SSL switch management

 DHCP client for IP address assignment

 DHCP Option82 and DHCP Relay

 Link Layer Discovery Protocol (LLDP) for easy network management

 Built-in Trivial File Transfer Protocol (TFTP) client

 Firmware upgrade via TFTP or HTTP

 Configuration restore / backup via TFTP or HTTP

 Event message logging to remote Syslog server

 Four RMON groups 1, 2, 3, 9 (history, statistics, alarms, and events)

 SNMP trap for interface Link Up and Link Down notification

 Supports Ping function

 Reset button for system reboot or reset to factory default

 1 RS-232 male DB9 console interface for Switch basic management and setup
