User’s Manual of VC-820M / VC-2400MR Series

• NoAuth: None authentication and none privacy.

• Auth: Authentication and none privacy.

• Authpriv: Authentication and privacy.

Read View:

The name of the MIB views defining the MIB objects for which this request may

request the current values.

The allowed string length is 1 to 16.

Write View:

The name of the MIB views defining the MIB objects for which this request may

potentially SET new values.

The allowed string length is 1 to 16.

Notify View:

Set up the notify view.

Remove Check to delete the selected entry. It will be deleted during the next save.

4.2.

.8 SNMP V3 usm-user

Configure SNMPv3 users table on this page. The entry index keys are Engine ID and User Name.

The SNMPv3 Users Configuration screen in Figure 4-2-12 appears.

Figure 4-2-12: SNMP configuration interface

The page includes the following fields:

Object Description

SNMP User Name:

A string identifying the user name that this entry should belong to. The allowed

string length is 1 to 15.

Auth Type:

Indicates the authentication protocol that this entry should belong to. Possible

authentication protocol are:

• None: None authentication protocol.

• MD5: An optional flag to indicate that this user using MD5 authentication

protocol.
