User’s Manual of VC-820M / VC-2400MR Series

4.2.

.4 Trap Managers

A trap manager is a management station that receives the trap messages generated by the switch. If no trap manager is

defined, no traps will be issued. To define a management station as a trap manager, assign an IP address, enter the SNMP

community strings, and select the SNMP trap version.

Figure 4-2-8: Trap Managers interface

The page includes the following fields:

Object Description

IP Address:

Enter the IP address of the trap manager.

Community:

Enter the community string for the trap station.

4.2.

.5 SNMPv3 Groups

Configure SNMPv3 groups table on this page. The entry index keys are Security Model and Security Name.

The SNMPv3 Groups Configuration screen in Figure 4-2-9 appears.

Figure 4-2-9: SNMP configuration interface
