SiE30-408 Collection and Playback of Data on Checker
Service Checker Type3 Application Edition 167
Enter the title of graph and
X- and Y-axis items.
Click on the “Legend” tab.
Click on the “Next”button.
Check the “Top”.
Click on the “Finish”button.
Check the “As new sheet”.
These items can be entered in
later stage.
