Collection and Playback of Data on Checker SiE30-408
166 Service Checker Type3 Application Edition
2. Plotting in Graph
There are cases where it is hard to keep track of the overall variations of data on the CSV data.
In this case, graphing the data will facilitate the verification of the data.
(The following section shows an example of the graphing procedure.)
1. Method of graphing and organizing a global sheet.
Run the graph wizard (graph insert).
Type of graph: “Line chart”
Form: “Shown in left figure”
Click on the “Next”button.
Graph wizard
Click on the “Next”button.
Graph insert
