Planet SGSW-24240R [208/328] Stack port state ovewview

User’s Manual of WGSW-24040 / WGSW-24040R

SGSW-24040 / SGSW-24040R

208

Figure 4-16-9 Stack Information page screenshot - Master Forwarding Table

4.16.4 Stack Port State Ovewview

This page provides an overview of the current switch port states. Clicking on the image of a port opens the Port Statistics

page.The port states are illustrated as follows:

Figure 4-16-10 Port State Overview page screenshot

MASTER LED

SWITCH ID

Port Link status

Stack Port Link status
