User’s Manual of WGSW-24040 / WGSW-24040R
SGSW-24040 / SGSW-24040R
87
Figure 4-4-7 SFP Module Information page screenshot
The page includes the following fields:
Object Description
• Type
Display the type of current SFP module, the possible types are:
• 1000Base-SX
• 1000Base-LX
• 100Base-FX
• Speed
Display the spedd of current SFP module, the speed value or description is get
from the SFP module. Different vendors SFP modules might shows different
speed information.
• Wave Length(nm)
Display the wavelength of current SFP module, the wavelength value is get from
the SFP module. Use this column to check if the wavelength values of two nodes
are the matched while the fiber connection is failed.
• Distance(m)
Display the supports distance of current SFP module, the distance value is get
from the SFP module.
